Descrizione
Questa versione del MultiPlus è destinata alle reti a 120 V: l’ingresso in alternata accetta da 95 a 140 VAC e l’uscita è a 120 VAC, su un impianto in continua a 12 V.
Nello stesso involucro convivono un inverter a onda sinusoidale vera e un caricabatterie con curva adattiva, oltre alla tecnologia ibrida PowerAssist e alle funzioni di integrazione di sistema. Il collegamento agli altri apparecchi passa da VE.Bus.
Contenitore in alluminio, protezione IP21, peso 19 kg. Conformità EN 55014-1 ed EN 55014-2, EN-IEC 61000-3-2 ed EN-IEC 61000-3-3, EN-IEC 61000-6-1, 61000-6-2 e 61000-6-3.
Caratteristiche tecniche
| Dimensioni strumento | 218 mm |
|---|---|
| Materiale | Aluminium |
| Colore luce/CCT | Blue (RAL 5012) |
| Protezione IP | IP21 |
| Peso strumento | 19 kg |
| Omologazioni e certificazioni | EN 55014-1,EN 55014-2,EN-IEC 61000-6-1, EN-IEC 61000-6-2,EN-IEC 61000-6-3,EN-IEC 61000-3-2,EN-IEC 61000-3-3 |
| Connettività audio | True |
| Tensione uscita | 120 VAC |
| Potenza di uscita sonar | 1,700 W |
| Tensione ingresso | [95, 140] VAC |
| Temperatura di esercizio | [-40, 65] °C |
| Corrente di carica/uscita | 4 A |
| Efficienza | 93 % |
| Remote terminal type | Screw terminal two pole |
| Relay terminal type | Screw terminal 3-pole |
| VE.bus communication port | Two RJ45 terminals |
| AC connection terminal type | Screw terminals 13 mm² (6 AWG) |
| Battery connection terminal type | M8 bolts (two for positive and two for negative connection) |
| Charge voltage storage (adjustable) | 13.2 VDC |
| Communication Port | VE.Bus |
| Nominal battery voltage | 12 V |
| Charge algorithm | Adaptive, 4-stage |
| Charge voltage absorption (adjustable) | 14.4 VDC |
| Charge voltage float (adjustable) | 13.8 VDC |
| AC output frequency ±0.1% (adjustable) | 60 Hz |
| AC input frequency range | [45, 65] Hz |
| Parallel operation | True |
| Temperature Sensor | Included |
| Three phase operation | True |
| Peak power rating | 6,000 W |
| Number of AC Outputs | 2 |
| Transfer switch AC current rating | 50 A |
| Number of AC Inputs | 1 |
| Programmable relay | AC rating: 230V / 4A, DC rating: 4A up to 35VDC and 1A up to 60VDC |
| Power Factor | 1 |
| Remote terminal | On / Off / Charger only |
| PowerControl | True |
| PowerAssist | True |
| Starter battery charge output | True |
| DIP switches for programming | True |
| Protections | Output short-circuit,Overload,High battery voltage,Low battery voltage,Over temperature,AC voltage on inverter output,Excessive DC ripple |
| Continuous power at 25°C (Nonlinear load, crest factor 3:1) | 3,000 VA |
| Programming via computer or app | True |
| General purpose communication port | True |
| Zero Load Power | 20 W |
| Zero load power in AES mode | 15 W |
| Maximum humidity (non-condensing) | 95 % |
| Zero load power in search mode | 8 W |
| Fan assisted cooling | True |
